KM1024i MAE-C 14PL Print Head Konica

Rating
$781.00
Tax excluded
Quantity

Description

Konica KM1024i MAE-C 14PL print head

New Original Konica 1024i MAE-C 13PL Print Head

Km1024i Mae-c Printhead Wholesale Original Konica KM1024i MAE-C Water Based Printhead

The Konica Minolta KM1024i MAE-C printhead has a high-density structure featuring 4 lines of 256 nozzles aligned with high precision enhances positioning accuracy to realize high-definition print quality at high speed printing.

The Konica Minolta KM1024i MAE-C printhead is a robust, shear mode, piezo on-demand printhead featuring an All-nozzle Independent Drive System with a Multi-line Structure. In contrast with the existing 3-cycle system drive, an independent drive system that enables simultaneous emission from all 1024 nozzles has been adopted. The high-density structure featuring 4 lines of 256 nozzles aligned with high precision enhances positioning accuracy to realize high-definition print quality. The Konica Minolta KM1024i MAE-C printhead offers a Maximum Drive Frequency of 27kHz, which makes it the ideal inkjet printhead for development of single-pass system inkjet printers capable of high-speed printing.

Environmentally-considerate Approved Green Product
The Konica Minolta KM1024i MAE-C printhead incorporates only approximately one-third of the petroleum-derived materials and toxic chemicals used in the current KM1024 Series. In addition, the nozzle unit surface area is the same as that of the KM1024 Series.

 Specifications:

• Technology: Piezo Drop On-Demand
• Native Resolution: 360 dpi
• Cal. Droplet Size: 14 pico litre
• Max. Drops in Greyscale: 8 drops
• Tot. Amount of Nozzles: 1024 (256 nozzles per line)
• Print Width: 72 mm
• Firing Frequency: 27 kHz
• Ink Compatibility: Water Based Inks
• Dimensions: W131mm x D18mm x H94mm
• Weight: Approx. 150g

Printer compatibility :

   Human Digital Technology QP-Jet

   Konica Nassenger Pro 120
