KM1024 MNB 14pl Printhead Konica Minolta

MNB Printhead Original Konica KM1024/14PL MNB Print Head

New and original 100% Konica minolta solvent printhead 1024/14pl KM1024 MNB print heads

konica Minolta 1024 KM1024 MNB KM1024LNB KM1024MHB KM1024LHB printhead

The Konica Minolta KM1024 MNB print head is compatible with oil based and solvent inks.


 The Konica Minolta KM1024 MN print head is a robust, shear mode, piezo on-demand print head that is usable in both binary and 8 level greyscale mode, providing variable drop size and higher print quality without the use of additional print heads. The Konica Minolta KM1024 MN print head is a vast improvement over the KM512 print head series, offering twice the print width and double the level of greyscale.

 Konica Minolta piezo on-demand inkjet heads are driven using lower voltages than other inkjet heads and the new actuator used in the KM1024 reduces power consumption even further. The Konica Minolta KM1024 MN print head has 1024 nozzles with a droplet size of 14 pico litre and a native resolution of 360 dpi.

 The print head is compatible with oil based and solvent inks. This print head is also known as the Konica Minolta KM1024 MNB. This is Konica original print head and it includes the necessary waveform information. It carries a product warranty.

Specifications :
    Technology: On-Demand Piezo Electric (Shared Wall 3 Cycle)
    Native Resolution: 360 dpi
    Cal. Droplet Size: 14 pico litre
    Max. Drops in Greyscale: 8 drops
    Tot. Amount of Nozzles: 1024 (512 nozzles per line)
    Nozzle Spacing: 70.5 microns
    Print Width: 72 mm
    Firing Frequency: 12.8 kHz
    Ink Compatibility: Oil Based and Solvent Inks
    Heater: not integrated

Agfa
   Anapurna M1600
   Anapurna M²
   Anapurna M2050
   Anapurna M2500
   Anapurna M2540 FB

Allwin C8

   DGI VE-3206
   DGI VelaJet VE-3204
   DGI VE-3204D

Dilli
   Neo Titan FB2513-06DW
   Neo Titan UVT-1604D

Scorpion
   ASLAN 5100
   3300 SE
