XLJet Motor, 1Phase,200V,1HP,750W,3000RPM - CW980-00140

Rating

This Motor,1Phase,200V,1HP,750W,3000RPM is suitable for HP Scitex XL1500 (XLJet+), FB7500 and Scitex FB7600 printers.
SKU: CW980-00140
Manufacturer part number: CW980-00140
$501.00
Tax excluded
Quantity

Description

Description

This Motor,1Phase,200V,1HP,750W,3000RPM is suitable for HP Scitex XL1500 (XLJet+), FB7500 and Scitex FB7600 printers. This is the original HP Scitex part (number CW980-00140 replacing number 316000022). The motor has a capacity of 750W, uses 230V and 4.4 A. It has a maximum rotation of 3000 r/min and the rated torque is 2.9 Nm. This AC Servo Motor is has a Class B insulation, is rated for an ambient temperature between 0 and 40°C and an ambient humidity between 20 and 80% non condensing.

Printer compatibility

HP Scitex FB7500
HP Scitex FB7600
HP Scitex XL1200 2.2M (XLJet 2)
HP Scitex XL1200 3.2M (XLJet 3)
HP Scitex XL1200 5M (XLJet 5)
HP Scitex XL1500 2.2M (XLJet +2)
HP Scitex XL1500 3.2M (XLJet +3)
HP Scitex XL1500 5M (XLJet +5)
